OUR PRODUCTS
Rotary exit section MH/DH
| Structures | Building, Other |
|---|---|
| Fastening surface | Concrete, Masonry, Other, Steel |
| Surface of the substrate | Other, Plane (flat) |
| Fall protection | Fixed ladder, Guide rail |
| Fall protection material | Stainless steel, Steel hot dipped galvanized |
The rotary exit section is used for safe transfer to a level behind the climbing path. Repositioning is possible to the left and to the right.
- Available in steel and stainless steel
- A rest platform, foldable, and a work platform are recommended for use
- It is recommended to have the design of the rotary exit section carried out by the manufacturer and to order it with a pre-assembled ladder segment.
2 variants for your requirements
Fastening to the guide rail every 560 mm.
Fastening to the structure with at least two fastening clamps.
Steel
Steel St-tZn (1.0037 hot-dip galvanized)
- incl. Screws
- Weight: from 5,4kg
Stainless steel
Stainless steel, pickled (1.4401/1.4571)
- incl. Screws
- Weight: from 5,4kg
- Factory mounting on conductor segment possible - specify when ordering
These components you need for your fall protection system
- Guide rail or ladder with integrated guide rail
- Fastening element
- Profile connector
- Climbing lock bottom 12 kN
- Climbing lock top 12 kN
- Identification plate
- Collecting device
